MODEL |
TC-1250H |
|
Dai.of column |
300 |
A |
Distance from column surface to spindle center , Max |
1275 |
D+C |
Distance from column surface to spindle center , Min |
305 |
C |
Travel of spindle head |
970 |
D |
Distance from base surface to spindle end , Max |
1330 |
E |
Distance from base surface to spindle end , Min |
438 |
F |
Elevating height of Arm |
625 |
E-F-I |
Effective area of box table |
635x520x420 |
L×K×H |
Dimension of base |
1830x785x185 |
R×S×Q |
Taper hole spindle |
MT#5 |
|
Stroke of spindle |
270 |
I |
R.P.M of spindle (rpm x steps) |
50HZ |
44-1206×12 steps |
|
60HZ |
56-1450×12 steps |
|
Feed of spindle (rev. x steps) |
0.06, 0.10, 0.20x3 steps |
|
Main motor (HP) |
5 (two speed motor) |
|
Elevating motor (HP) |
1HP |
2HP |
|
Hydraulic clamping motor (HP) |
1HP |
|
Coolant equipment (HP) |
1/8 HP |
|
Machine height from floor (Max.) |
2795 |
M |
Base + column height |
2070 |
G |
Net weight (approx)kgs |
2300 (kg) |
|
S Shipping weight (approx)kgs |
2500 (kg) |
|
Shipping dimensions (LxWxH) |
2220×1000×2240 |
|
Capacity |
Drilling |
Stell |
50Φ |
|
Cast iron |
60Φ |
|
Tapping |
Stell |
40Φ |
|
Cast iron |
50Φ |
|
